class: center, middle, inverse, title-slide # Version control with Git ### Netherlands eScience Center - Small Scale Initiative Machine Learning --- # Let's do this! The collaborative doc: [tinyurl.com/ssi-ml-day2-introduction-git](https://tinyurl.com/ssi-ml-day2-introduction-git) .pull-left[ - Note in the document: - The **command log**, where we will store commands in live coding sessions - The **notes**, where we will add resources and tips discussed - The **check-in**, where we will ask for your answers - Please ask for help in Discord: #questions channel - Close as many unnecessary windows and programs as possible. ] -- .pull-right[ | | Our schedule | |:--|:--| |9:00 | Introduction to Git & each other| |_10:00_ | _break_ | |10:15 | Git and GitHub (/BitBucket/GitLab) | |_11:15_ | _break_| | 11:30 | Workflow with Git | | 12:30 | _end_ | ] --- # Before we start Please check that your SSH key pair is working. Github: ```bash ssh git@github.com ``` Gitlab: ```bash ssh -T git@gitlab.example.com ``` - If you need to verify the authenticity of the host? Type `yes` - You should then see something like: ``` Hi bvreede! You've successfully authenticated, but GitHub does not provide shell access. Connection to github.com closed. ``` Use the check-in to let us know that your SSH works! --- # Why do you need version control? .pull-left[ - It will help you manage ~~your code~~ most of your files (it is like track changes on steroids: it applies to all files in a folder). - It allows you to trace back your steps: if something breaks, you can figure out what happened. - NO MORE thesis_final_final_SERIOUSLYFINAL.Rmd ] .pull-right[ <img src="http://www.phdcomics.com/comics/archive/phd101212s.gif" width="400" /> ] --- # Why do you need version control? .pull-left[ #### But even better: - a good version control system allows you to collaborate and share; - it can facilitate controlled addition of new features; - you can experiment without breaking your project! ] .pull-right[ <img src="http://www.phdcomics.com/comics/archive/phd101212s.gif" width="400" /> ] --- # What is Git? .pull-left[ - Distributed version control system: everyone works on their own copy, a distinct entity from the remote repository. - Open Source, written by Linus Torvalds (of Linux fame) - Well-known and much used, current standard for software - Very efficient use of storage, while retaining all history - Key version control system for the website **Github** (and others) ] .pull-right[ ![](images/distributed.png)<!-- --> ] --- # But OMG the command line! .pull-left[ - Yes, Git is written for the command line... - ... but many GUI-clients exist nowadays... - ...and most coding IDEs have built-in Git! _Also, pst... most of my Git skills come from sticky notes and stackoverflow._ ] .pull-right[ ![git](https://imgs.xkcd.com/comics/git.png) ] --- # How does Git work? .pull-left[ #### Log the changes in a narrative way - `commit` a (set of) changes, with a designated message ] .pull-right[ ![](https://swcarpentry.github.io/git-novice/fig/play-changes.svg) ] --- # How does Git work? .pull-left[ #### Log the changes in a narrative way - `commit` a (set of) changes, with a designated message #### Branch off to work on a new feature - Work on a new feature or experiment on a dedicated `branch` or `fork` ] .pull-right[ ![](https://swcarpentry.github.io/git-novice/fig/versions.svg) ] --- # How does Git work? .pull-left[ #### Log the changes in a narrative way - `commit` a (set of) changes, with a designated message #### Branch off to work on a new feature - Work on a new feature or experiment on a dedicated `branch` or `fork` #### Merge back to apply the new feature - `pull` or `merge` a collection of changes to combine them with the current state ] .pull-right[ ![](https://swcarpentry.github.io/git-novice/fig/merge.svg) ] --- # How does Git work? .pull-left[ #### Log the changes in a narrative way - `commit` a (set of) changes, with a designated message #### Branch off to work on a new feature - Work on a new feature or experiment on a dedicated `branch` or `fork` #### Merge back to apply the new feature - `pull` or `merge` a collection of changes to combine them with the current state #### Work locally, publish remotely - Git works perfectly fine if only used locally... - ...but shines in combination with Github! ] .pull-right[ ![](images/git-escience/ewc_on_github.png) ] --- class: inverse, center, middle # Let's make a repository! --- # Gitignore [github.com/github/gitignore](https://github.com/github/gitignore) --- # Your workflow ![](https://images.osteele.com/2008/git-transport.png)<!-- --> .footnote[credit: [osteele.com](https://blog.osteele.com/2008/05/my-git-workflow/)] --- # Your workflow What command do you use when you want to download remote changes? 1. ```bash git pull ``` 2. ```bash git commit ``` 3. ```bash git push ``` --- # Your workflow What command do you use when you want to log new changes? 1. ```bash git pull ``` 2. ```bash git commit ``` 3. ```bash git push ``` --- # Enjoy, but git responsibly - **Don't** leave work without committing it! - **Do** commit multiple files together if they form a comprehensive change -- - **Don't** get frustrated :) - **Do** use meaningful commit messages. ![](https://imgs.xkcd.com/comics/git_commit.png)<!-- --> -- - **Do** Track most files; .gitignore those files you don't. - **Don't** Experiment on your master/main branch: use feature branches for exploration! --- class: inverse, center, middle # NB. The following slides are not meant for teaching :) --- Set up your system to use git! ```bash git -h git config --global user.name "Barbara Vreede" git config --global user.email "b.vreede@esciencecenter.nl" # or you can keep the user name private git config --global user.email bvreede@users.noreply.github.com git config --list ``` In Git, the project folder is central. ```bash cd Sandbox mkdir beautiful_soup cd beautiful_soup git init git branch -m main ``` --- Adding ingredients to our soup ``` nano soup.md ``` Write in Nano: ``` # Beautiful soup ## Ingredients - 3 carrots - 2 sticks of celery - 1 onion - as much garlic as you can find - cilantro ``` Close with `ctrl + X` > `Y` > `enter` Add it to git ``` git add soup.md git commit -m "the ingredients for my soup" ``` --- - Make a repo on Github - Copy the SSH address ``` git remote add origin git@github.com:bvreede/beautiful_soup.git ``` Made a mistake? Need to change protocol? ``` git remote set-url origin <the-actual-address> ``` Connect your local repo to the remote ```bash git push -u origin main ``` --- Add a readme in github ```bash git pull ``` --- Add a recipe ```bash nano soup.md ``` Write in Nano: ``` ## Recipe 1. Cut all the veggies 2. Throw them in a pan 3. Turn up the heat 4. Add some water 5. Enjoy ``` Close with `ctrl + X` > `Y` > `enter` --- - workflow add > commit > push - what happens with a merge conflict: make an edit remotely and locally and pull the change - Nano delete lines with `^K` - git status - git log - git log --oneline - git log --oneline --graph - git diff - make a directory, show nothing happens: git tracks files --- # exercise Which command(s) below would save the changes of myfile.txt to my local Git repository? 1. ```bash $ git commit -m "my recent changes" ``` 2. ```bash $ git init myfile.txt $ git commit -m "my recent changes" ``` 3. ```bash $ git add myfile.txt $ git commit -m "my recent changes" ``` 4. ```bash $ git commit -m myfile.txt "my recent changes" ``` --- # history ```bash git diff HEAD~1 soup.md git diff HEAD~3 README.md git show 6ba95cb git status git checkout HEAD~1 git git switch -c newbranch ``` --- # ignoring ```bash nano .gitignore ``` ---
